Load Rotation Device for Heavy Loads

Product Description

A heavy load rotation device is a specialized lifting attachment installed under crane hook. It enables continuous 0° - 360° rotation or fixed angle turning (such as 90°, 180° or 360°) of workpieces during lifting operations. Its core function is to adjust workpieces between different positions to meet process requirements including welding, assembly, inspection and painting.

Structure of the Load Rotation Device

Load-Bearing Structure: Adopts high strength steel structure and reinforced beam frame to bear workpiece load and dynamic load, and evenly transmit stress to the hoisting system.

Drive System: Adopts servo electric drive to realize stable turning of workpieces.

Load Turning Slings: Made of chains or high strength fiber belts for power transmission and synchronous control.

Control System: Equipped with wireless remote control and intelligent PLC control, which prevents load deviation and swinging during workpiece turning.

Safety Protection System: Integrates overload protection, limit switches, emergency stop buttons, mechanical locking mechanism and dual braking system to reduce the risk of equipment malfunction.

Working Principle

• Secure the workpiece with chain or belt slings.

• The crane lifts the turning device to the working height.

• The drive system is activated to drive the rotating mechanism.

• The control system adjusts rotating speed and angle.

• Lock the position after turning and proceed with lifting operations.

Technical Parameters (Customizable)

Product Advantages of Load Rotation Device

• Automated turning significantly reduces operation time.

• Minimizes manual handling and improves workplace safety.

• Suitable for irregular and deformation-prone workpieces.

• Fully customizable based on size, weight and process requirements.

• Compatible with overhead cranes and gantry cranes.

Industry Applications

Steel Structure Fabrication: H-beam turning, heavy component assembly

Shipbuilding Industry: Hull section turning, engine component rotation

Automotive Manufacturing: Chassis turning, frame assembly

Casting Industry: Large mold turning, casting flipping

New Energy & Heavy Equipment: Wind power components handling, pressure vessel rotation

If you are looking for a high performance customized load turning solution, feel free to contact us for professional technical support and tailored design services.
