Load Turning Device

Product Description

The load turning device is a mechanical device designed for turning and positioning large or irregular workpieces. It can accurately turn heavy objects in horizontal or vertical planes, and realize multi-angle accurate turning from 90° to 360°, providing efficient and safe operation support for welding, assembly, inspection, cleaning, painting and other processes. Through electric drive, chain drive synchronization and multiple locking protection, it can meet a variety of turning needs from light load to super heavy load.

Main Features of Load Turning Device

  ● Rated load range 1t - 50t, meeting the turning needs of workpieces of different specifications.

  ● Support 0° - 180° and any intermediate locking angle, some models can achieve ±360° continuous turning.

  ● Driven by electric reducer, the electric system is small in size and precise in control; the hydraulic system has large torque and strong impact resistance.

  ● Overload protection, mechanical limit switch, emergency stop button, chain anti-break protection, etc., to ensure the safety of personnel and equipment.

  ● Optional anti-corrosion, dustproof, explosion-proof and high temperature environment special configurations are suitable for special working conditions such as casting, chemical industry, coal mining, etc.

Main Technical Parameters (For Reference)

  ● Rated load: 1 - 50 tons (customization supported)

  ● Turning angle: 0 - 360°

  ● Turning speed: 1 - 5 °/s (adjustable)

  ● Drive mode: Electric

  ● Synchronization accuracy: ±1°

  ● Control mode: Remote control/PLC

  ● Safety device: Overload sensor, emergency stop, chain break protection

  ● Power supply requirement: 380V/50Hz

Selection and Customization Suggestions

  ● Determine the load and turning requirements: Reserve 10%–20% safety margin according to the weight and size of the workpiece; select the required turning angle and speed.

  ● Safety and environmental configuration: For flammable, explosive or corrosive environments, explosion-proof motors, anti-corrosion coatings and dust covers are required.

  ● System integration: It can be connected to the PLC automation system to realize the automation and monitoring of the turning process.

  ● Maintenance plan: Automatic lubrication system and modular wearing parts configuration are recommended to reduce downtime and maintenance costs.

The load turning device provides safe, efficient and flexible workpiece turning solutions for various industrial applications through high load capacity, precise synchronous control and multi-angle turning functions. We can provide non-standard customized designs according to your specific needs. Please feel free to contact our technical team.
